Over ventilated tub - Inclined

03.04.00

Over ventilated tub is used for the circulating of cooled air to keep all products at the ideal temperature. You can find the dimensional types of this product in the "variants".

Datasheet: Download
Manual: Download
Electrical schema: Download
Over ventilated tub is used for the circulating of cooled air to keep all products at the ideal temperature. Two position of the plate - straight or inclined the plate can be folded upwards with evaporator (37°) for cleaning and locked in the top position. Aggregate: Separate or integrated. Model 2EN and 3EN as one tub, model 4EN as one tub or combination of two tubs. Specifications: Temperature: +4°C ~ +8°C, Cooling medium: R290. You can find specific performance details in the datasheet.
Product number Name X width Y height Z depth
V2-030400-0197 Over ventilated tub - Inclined 5° (Aggregate) 894mm 619mm 781mm
V2-030400-0198 Over ventilated tub - Inclined 5° 3EN (Aggregate) 1294mm 619mm 781mm
V2-030400-0168 Over ventilated tub - Inclined 5° 4EN (Aggregate) 1747mm 619mm 781mm
V2-030400-0167 Over ventilated tub - Inclined 5° 4EN 2+2 (Aggregate) 1747mm 619mm 781mm
V2-030400-0231 Over ventilated tub - Inclined 5° 2EN (Central cooled) 894mm 259mm 781mm
V2-030400-0232 Over ventilated tub - Inclined 5° 3EN (Central cooled) 1294mm 259mm 781mm
V2-030400-0234 Over ventilated tub - Inclined 5° 4EN (Central cooled) 1747mm 259mm 781mm
V2-030400-0233 Over ventilated tub - Inclined 5° 4EN 2+2 (Central cooled) 1747mm 259mm 781mm
V2-030400-0235 Over ventilated tub - Inclined 8° 2EN (Aggregate) 894mm 660mm 781mm
V2-030400-0236 Over ventilated tub - Inclined 8° 3EN (Aggregate) 1294mm 660mm 781mm
V2-030400-0166 Over ventilated tub - Inclined 8° 4EN (Aggregate) 1747mm 660mm 781mm
V2-030400-0165 Over ventilated tub - Inclined 8° 4EN 2+2 (Aggregate) 1747mm 660mm 781mm
V2-030400-0241 Over ventilated tub - Inclined 8° 2EN (Central cooled) 894mm 300mm 781mm
V2-030400-0242 Over ventilated tub - Inclined 8° 3EN (Central cooled) 1294mm 300mm 781mm
V2-030400-0244 Over ventilated tub - Inclined 8° 4EN (Central cooled) 1747mm 300mm 781mm
V2-030400-0243 Over ventilated tub - Inclined 8° 4EN 2+2 (Central cooled) 1747mm 300mm 781mm
Image Product number Name
Image Product number Name
97-502 Thermostat DIXELL XR60CH
97-011 Switch - double
97-038 Switch cover - double
